The BlueSupra™ series tags have an AISI 304 stainless steel body to work even in the most extreme working environments and resist over time.
They are compliant with MIL-STD 810H, resistant to impacts (IK10), dust and water (IP68).
Stainless Steel Shell – MIL-STD 810H
■ An NFC-enabled mobile device or smartphone can be used as a reader (iOS 14 or later / Android 12 or later required).
■ It meets the requirements of the US military standard MIL-STD-810H.
■ It meets the IK10 impact protection level.
■ It meets the highest level of dust and water resistance IP68.
■ Unique design.
■ Patents in multiple countries.
■ Using Supra Digital Chips with RiConnect software (or other compatible) you can achieve: product traceability, manufacturer authentication and digitized product information.
■ Materials: SUS 304 stainless steel (polished) resistant to corrosion.
■ Dimensions (mm): Ø16×10
■ It meets the requirements of the US military standard MIL-STD-810H.
■ It meets the IK10 impact protection level.
■ It meets the highest level of dust and water resistance IP68.
■ Reading via NFC-enabled smartphone (iOS 14 or later, Android 12 or later).
■ RF protocol ISO 15693.
■ Operating frequency HF – 13.56 MHz.
■ Memory configuration 16 characters UID, 2000 bits.
■ IP Rating IP68.
■ Reading and writing capabilities.
■ Reading range: maximum 5 mm.
■ SUPRA™ digital chips work seamlessly with RiConnect software, but also with third-party asset management software.
■ Exposure temperatures: -30 + 125°C
■ Continuous exposure temperatures: -30 + 125°C
■ Waterproof and ice-proof.
■ Operation up to 6000 meters deep.
For further information, please contact us: our sales technicians will indicate the most suitable products for your applications.
