Swivel lifting point (female) with ring, intended for lifting loads; to be installed on the load itself via a threaded hole.
■ Made of high-strength grade 80 steel alloy.
■ Mounted on ball bearings to be able to rotate even under the weight of the load.
■ 360° orientable with 230° folding ring.
■ Wide range of capacities available (M8-M100, 0.4-40 tons).
■ Compliant with DM2006/42/CE and EN1677-1.
■ Tested in accordance with EN1677-1 and DM2006/42/CE.
■ All load-bearing elements are 100% Magnaflux verified.
■ Tested at 2.5 times the WLL.
■ Fatigue test at 20,000 cycles at 1.5 times the WLL.
■ Metric thread, sizes: M8 – M100.
■ Load capacities: 0.4 t – 40 t.
■ Identical load capacity in all load directions
■ 360° rotatable with 230° folding ring.
■ Mounted on ball bearing to rotate even under the weight of the load.
■ Made of high-strength grade 80 alloy steel: precision forging and heat treatment to achieve high resistance.
■ Epoxy resin coating to effectively prevent surface corrosion.
■ Clear engraving of the manufacturer’s name, load capacity (WLL), CE mark, thread on the body of the eyebolt.
■ Hexagonal base design for easy assembly.
■ Safety factor 4:1.
■ Tested to EN1677-1.
■ Individual forged parts and screws are traceable to the test certification.
■ Bolts are metric thread.
■ Nominally loaded parts are 100% Magnaflux tested after heat treatment.
■ Tested to 2.5 times WLL.
■ Tested to 20,000 fatigue cycles.
Different thread types and shank lengths available on request. The device is not suitable for rotation under load.
Caution: Do not exceed the working load rating (WLL).
