SupraRing – 13279 Digital Chip
26 March 2025
Swivel lifting point with joint, intended for lifting loads; to be installed on the load itself via a threaded hole.
■ Made of high-strength grade 80 steel alloy.
■ 360° orientable with 180° folding bracket.
■ Wide range of capacities available (M8-M100, 0.5-50 t).
■ Compliant with Standard EN1677-1.
■ Possibility of long screw.
■ Tested in accordance with EN1677-1 and DM2006/42/CE.
■ All load-bearing elements are 100% Magnaflux verified.
■ Tested at 2.5 times the WLL.
■ Fatigue test at 20,000 cycles at 1.5 times the WLL.
■ Quick and easy assembly, only one threaded hole is required.
■ Metric thread, sizes: M8 – M100.
■ Load capacities: 0.5 t – 50 t.
■ Identical load capacity in all load directions.
■ 360° rotatable with 180° tilting bracket.
■ Made of high-strength grade 80 alloy steel: precision forged and heat treated for high performance.
■ Epoxy resin coating, effectively preventing surface corrosion.
■ Clear engraving of the manufacturer’s name, WLL, CE mark, thread on the body of the eyebolt.
■ Safety factor 4:1.
■ Tested in accordance with EN1677-1.
■ Individual forged parts and screws are traceable to the test certification.
■ Bolts are metric thread.
■ Load bearing parts are 100% Magnaflux tested after heat treatment.
■ Tested to 2.5 times WLL.
■ Tested to 20,000 fatigue cycles.
■ Possibility of long screw.
Different thread types and shank lengths available on request. The device is not suitable for rotation under load.
Caution: Do not exceed the working load rating (WLL).
