ENDLESS LASHING WITH RATCHET BUCKLE
30 August 2022
What are
BEGNI Group COBRA® lashings are made of high tenacity polyester webbings and steel components (ratchet buckles and hooks). They compliant with EN12195-2.
They consist of 2 parts:
- fixed length (ratchet buckle + webbing + hook).
- Loose end length (webbing + hook).
Benefits
- Easy to handle and to use.
- Strong PVC label with general precautions.
- Possibility of customization: lashings can be customized by capacity (LC), by length, colour and printing with the customer’s name and logo.
- Choice of hook: it is possible to request different types of hooks.
- Large stock in the warehouse: the wide availability of products allows very fast delivery times to process even the most urgent orders.
- Procurement contracts: Begni Group is available to sign framework agreements with which to guarantee large quantities of product available to the customer and fix the price for long periods.
Technical features
- High tensile strength.
- Superior resilience and very low elongation (<7% of the lashing capacity, LC).
- High shock absorption (they can be retensioned in case of volume loss in packaged goods).
- Excellent UV resistance.
- Water resistance and very little moisture absorption.
- Good resistance against chemicals.
- Working and storing temperatures: -40 ÷ 100 °C.
- Compliant with EN12195-2, VDI 2700ff.
2 types:
ACT2035
- Webbing 35 mm / 3000 daN
- LC= 1000 daN
- STF= 200 daN
- MBL= 2000 daN
ACT3035
- Webbing 35 mm / 4500 daN
- LC= 1500 daN
- STF= 240 daN
- MBL=3000 daN
——–
Technical terms (according to EN12195-2)
LC: lashing capacity (for diagonal lashing).
STF: tension applied to the webbing belt (for frictional lashing).
MBL: lashing minimum breaking load.
Important Notice
Before using the products, carefully read the instructions for safe use.
For further information, please contact us: our sales technicians will indicate the most suitable products for your applications.
